SLITTING LINE MACHINE
Aogang Machinery Co., Ltd.
Aogang Machinery Co., Ltd.
The Aogang Steel Slitting Machine is specifically designed for precision processing of carbon steel, hot-rolled steel, cold-rolled steel, galvanized steel, and pre-painted steel coils. Featuring a robust mechanical structure and advanced automation technology, it delivers stable operation, precise strip width, and excellent edge quality for demanding steel coil processing applications. Customized configurations are available to meet different production requirements.
Aogang steel slitting machines are widely used in steel service centers, automotive manufacturing, home appliance production, construction, and metal fabrication industries. They are designed for precision processing of carbon steel, hot-rolled steel, cold-rolled steel, galvanized steel, and pre-painted steel coils.
By integrating advanced CNC technology with an intelligent automation system, the machine delivers precise strip width, smooth strip edges, and minimal burrs, meeting the requirements of stamping, cold roll forming, welding, and other downstream manufacturing processes.
Backed by extensive manufacturing experience and strong R&D capabilities, Aogang provides efficient, reliable, and customized steel coil slitting solutions. We offer comprehensive services including project consultation, equipment design, manufacturing, installation, commissioning, operator training, and long-term after-sales support to help customers improve productivity and maximize investment value.
✔ High-precision steel coil processing
✔ Customized slitting line solutions
✔ Advanced CNC control and stable operation
✔ Exported to over 60 countries
✔ Professional installation and long-term technical support
The Aogang steel slitting machine can process a wide variety of steel coils, including carbon steel, hot-rolled steel, cold-rolled steel, galvanized steel, and pre-painted steel. It can also be customized to accommodate different coil widths, material thicknesses, and production requirements.
The machine combines a rigid machine structure, a high-precision slitter head, advanced CNC control, and an intelligent tension control system to maintain excellent slitting accuracy, consistent strip width, and reliable performance during continuous production.
Yes. Aogang provides customized steel slitting solutions based on coil specifications, strip width, production capacity, automation level, and factory layout. Optional features are available to meet different processing requirements, ensuring optimal performance for your specific steel applications.
Steel slitting machines are widely used in steel service centers, automotive manufacturing, home appliance production, construction, metal fabrication, and other industries requiring precise steel coil processing.
Processes hot-rolled steel, cold-rolled steel, silicon steel, stainless steel, galvanized steel, etc.
Imported precision knife shaft bearings and high-quality alloy blades ensure smooth and burr-free cutting.
Fully automated system with auto-centering, tension control, and fault diagnosis for easy operation.
Fast knife replacement supports multi-specification and small-batch flexible production.
Equipped with high-efficiency drive systems, featuring low energy consumption and stable operation.
Special anti-scratch devices ensure the quality of coated or high-grade surface materials.
| Raw Material Specifications | Raw Material Width Range | 300–2500 mm | Custom special specifications available |
| Raw Material Thickness Range | Cold-rolled sheet: 0.3–3.5 mm / Hot-rolled sheet: 1.0–8.0 mm / High-strength steel: 1.0–6.0 mm | Configuration varies by material type | |
| Maximum Coil Weight | ≤30 T | Depends on equipment specification | |
| Finished Product Specifications | Slit Strip Width Range | ≥30 mm | |
| Equipment Performance | Maximum Operating Speed | ≤200 m/min | Depends on material thickness |
| Standard Operating Speed | Cold-rolled sheet: 50–200 m/min / Hot-rolled sheet: 30–120 m/min / High-strength steel: 20–80 m/min | ||
| Control System | Control Core | PLC + HMI | |
| Operation Mode | Fully Automatic / Semi-Automatic / Manual |
Through these video cases, you can directly experience Aogang’s strength and craftsmanship in high-end manufacturing—from precise installation and commissioning to the stable and efficient performance of our equipment. We provide fully customizable production lines to help customers achieve intelligent, one-stop solutions.
Reach out today to see how Aogang can support your tube mill needs
