The client is a major steel pipe equipment manufacturer in Mexico, primarily supplying pipe production equipment to the construction industry. In 2019, they purchased their first pipe production line from our company and achieved positive results. Recently, to expand their production capacity, the client placed another order for two 76 high-frequency steel pipe production lines, which have now been successfully delivered. The new lines have not only enhanced their production efficiency but also helped them further expand their market share in the Mexican steel pipe industry.
Line speed up to 80 m/min, single-shift capacity up to 45,000 tons, with a maximum pipe diameter of 76 mm
Covers the entire process from coil loading to finished product unloading
Integrated with an advanced eddy current testing system to ensure weld seam quality
Equipped with automatic stacking and bundling systems, significantly reducing labor costs
Fitted with motors and components from top international brands such as Siemens, Yaskawa, and Allen-Bradley
Parameters can be customized according to customer requirements.
| Finished Product Type | Size Range |
| Round Pipe | Φ22mm–Φ76mm, wall thickness: 0.9mm–4.0mm |
| Square / Rectangular Pipe | 19mm×19mm–60mm×60mm, wall thickness: 0.9mm–3.0mm |
| Finished Length | 5m–12m |
| Length Tolerance | ±1.5mm |
| Production Speed | 50–80 m/min |
Coil Types:
Hot-rolled / Cold-rolled Carbon Steel / Galvanized Steel Strip
High-Strength Low-Alloy Steel (HSLA)
Advanced High-Strength Steel (AHSS)
Material Width Range: 70mm–240mm
Material Thickness Range: 0.9mm–4.0mm
Coil Inner Diameter: Φ480–Φ520mm
Coil Outer Diameter: Φ800–Φ1800mm
Coil Weight: 2.5–3.0 tons
Reach out today to see how Aogang can support your tube mill needs
